Evolis Avansia Service Manual

Service Manual_AVA1_ENG-20220922_I 84
PM3: Turn
Action Check > PM3: Turn >
PM3:
Forward
Overview
Operation check of the Reverse Assembly Rotation Motor (PM3)
(counterclockwise)
Detail
To operate the Reverse Assembly Rotation Motor (PM3) for the
specified period of time (1
to 20 seconds) to the counterclockwise
direction.
Use Case
Checking the operation
Adj/Set/Operate
Method
Select
the item, and then press SET key.
Caution
•
Perform the checks without having a card in the card case or
reverse assembly.
• Because the printer becomes operation failure, do not press the
SET key to stop during operation. If it has been stopped, turn
OFF/ON the power switch.
PM3: Reverse
Overview
Operation check of the Reverse Assembly Rotation Motor (PM3)
(clockwise)
Detail
To operate the Reverse Assembly Rotation Motor (PM3) for the
specified period of time (1
to 20 seconds) to the clockwise direction.
Use Case
Checking the operation
Adj/Set/Operate
Method
Select the item, and then press SET key.
Caution
•
Perform the checks without having a card in the card case or
reverse assembly.
• Because the printer becomes operation failure, do not press the
SET key to stop during operation. If it has been stopped, turn
OFF/ON the power switch.
HB1: Card
Action Check > HB1 : Card >
HB1:
Forward
Overview
Operation check of the Card Feed Motor (Secondary Transfer
Assembly) (HB1) (feed direction)
Detail
To operate the Card Feed Motor (Secondary Transfer Assembly) (HB1)
for the specified pe
riod of time (1 to 20 seconds) to the feed direction.
Use Case
Checking the operation
Adj/Set/Operate
Meth
od
Select
the item, and then press SET key.
Caution
•
Perform the checks without having a card in the secondary
transfer assembly.
• Because the printer becomes operation failure, do not press the
SET key to stop during operation. If it has been stopped, turn
OFF/ON the power switch.
HB1: Reverse
Overview
Operation check of the Card Feed Motor (Secondary Transfer
Assembly) (HB1) (reverse di
- rection)
Detail
To operate the Card Feed Motor (Secondary Transfer Assembly) (HB1)
for the specified period
of time (1 to 20 seconds) to the reverse
direction.
Use Case
Checking the operation
Adj/Set/Operate
Method
Select the item, and then press SET key.
Caution
• Perform the checks without having a card in the secondary
transfer assembly.
• Because the printer becomes operation failure, do not press the
SET key to stop during operation. If it has been stopped, turn
OFF/ON the power switch.

Evolis Avansia Specifications

General

Color	Yes
Card size	85.6 x 53.98 mm
Card types	Polycarbonate, PVC, PVC Composite
Print technology	Dye-sublimation/Resin Thermal transfer
Print speed (color)	144 card/h
Card thickness (min)	0.76 mm
Duplex print speed (color)	96 card/h
Display	LCD
Lamination	-
Certification	CE, FCC, UL, IEC RoHS
Product color	Black, White
Internal memory	64 MB
Cable lock slot type	Kensington
Total input capacity	250 sheets
Wi-Fi	No
Security algorithms	IPSEC
Ethernet interface type	Fast Ethernet
Bundled software	cardPresso XXS
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	297 mm
Width	340 mm
Height	436 mm
Weight	20000 g
