Evolis Avansia Service Manual

Service Manual_AVA1_ENG-20220922_I 99
Product
Code
Product Description Step Page
CP011978
DECURL SPRING
15
161
CP010901
BOARD RFID
*
*
CP013577
BUSHING Ø6 Ø10 LG6 WITH FLATS
17
181
CP013456
FRONT COVER
18
182
CP013659
ROLLER: FILM
20
190
CP013457
ROLLER: PRINT PLATEN
19
184
• * = Replacement procedure not available
PARTS REPLACEMENT RECOMMENDATION
Product code
Name
Advice of replacement
CP013577
BUSHING Ø6 Ø10 LG6 WITH FLATS
50 000 cards
S10197
CLEANING ROLLER
40.000 cards
S10248
HEAT ROLLER
40.000 cards
CP013659
TRANSFER FILM feed roller
Whenever needed

Evolis Avansia Specifications

General

Color	Yes
Card size	85.6 x 53.98 mm
Card types	Polycarbonate, PVC, PVC Composite
Print technology	Dye-sublimation/Resin Thermal transfer
Print speed (color)	144 card/h
Card thickness (min)	0.76 mm
Duplex print speed (color)	96 card/h
Display	LCD
Lamination	-
Certification	CE, FCC, UL, IEC RoHS
Product color	Black, White
Internal memory	64 MB
Cable lock slot type	Kensington
Total input capacity	250 sheets
Wi-Fi	No
Security algorithms	IPSEC
Ethernet interface type	Fast Ethernet
Bundled software	cardPresso XXS
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	297 mm
Width	340 mm
Height	436 mm
Weight	20000 g
