Evolis Avansia Service Manual

Service Manual_AVA1_ENG-20220922_I 85
HB2: Film
Action Check > HB2 : Film >
HB2:
Forward
Overview
Operation check of the Film Feed Motor (HB2) (feed direction)
Detail
To operate the Film Feed Motor (HB2) for the specified period of time
(1
to 20 seconds) to the feed direction.
Use Case
Checking the operation
Adj/Set/Operate
Method
Select the item, and then press SET key.
Caution
•
Perform the checks without installing the transfer film cassette.
• Because the printer becomes operation failure, do not press the
SET key to stop during operation. If it has been stopped, turn
OFF/ON the power switch.
HB2:
Reverse
Overview
Operation check of the Film Feed Motor (HB2) (reverse direction)
Detail
To operate the Film Feed Motor (HB2) for the specified period of time
(1
to 20 seconds) to the reverse direction.
Use Case
Checking the operation
Adj/Set/Operate
Method
Select the item, and then press SET key.
Caution
•
Perform the checks without installing the transfer film cassette.
• Because the printer becomes operation failure, do not press the
SET key to stop during operation. If it has been stopped, turn
OFF/ON the power switch.

Evolis Avansia Specifications

General

Color	Yes
Card size	85.6 x 53.98 mm
Card types	Polycarbonate, PVC, PVC Composite
Print technology	Dye-sublimation/Resin Thermal transfer
Print speed (color)	144 card/h
Card thickness (min)	0.76 mm
Duplex print speed (color)	96 card/h
Display	LCD
Lamination	-
Certification	CE, FCC, UL, IEC RoHS
Product color	Black, White
Internal memory	64 MB
Cable lock slot type	Kensington
Total input capacity	250 sheets
Wi-Fi	No
Security algorithms	IPSEC
Ethernet interface type	Fast Ethernet
Bundled software	cardPresso XXS
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	297 mm
Width	340 mm
Height	436 mm
Weight	20000 g
