Service Manual_AVA1_ENG-20220922_I 145

Step 11 – CLEANING ROLLER STATION - S10197

1. Turn off the power.

2. Open the front cover

3. Remove the cleaning tape cassette (blue part).

4. Remove the cleaning tape cassette handle, lift it and pull.
