Evolis Avansia Service Manual

Service Manual_AVA1_ENG-20220922_I 83
ACTION CHECK
PM1: Card
Action Check > PM1: Card >
PM1:
Forward
Overview
Operation check of the Card Supply Motor (PM1)
Detail
To operate the Card Supply Motor (PM1) for the specified period of
time (1 to 20 seconds) to
the feed direction.
Use Case
Checking the operation
Adj/Set/Operate
Method
Select the item, and then press SET key.
Caution
•
Perform the checks without having a card in the card case or
reverse assembly.
• Because the printer becomes operation failure, do not press the
SET key to stop during operation. If it has been stopped, turn
OFF/ON the power switch.
PM2: Card
Action Check > PM2: Card >
PM2:
Forward
Overview
Operation check of the Card Feed Motor (Reverse Assembly) (PM2)
(feed direction)
Detail
To operate the Card Feed Motor (Reverse Assembly) (PM2) for the
specified period of time
(1 to 20 seconds) to the feed direction.
Use Case
Checking the operation
Adj/Set/Operate
Method
Select
the item, and then press SET key.
Action Check > PM2: Card >
PM2:
Forward
Caution
• Perform the checks without having a card in the card case or
reverse assembly.
• Because the printer becomes operation failure, do not press the
SET key to stop during operation. If it has been stopped, turn
OFF/ON the power switch.
PM2:
Reverse
Overview
Operation check of the Card Feed Motor (Reverse Assembly) (PM2)
(reverse direction)
Detail
To operate the Card Feed Motor (Reverse Assembly) (PM2) for the
specified period of time
(1 to 20 seconds) to the reverse direction.
Use Case
Checking the operation
Adj/Set/Operate
Method
Select the item, and then press SET key.
Caution
•
Perform the checks without having a card in the card case or
reverse assembly.
• Because the printer becomes operation failure, do not press the
SET key to stop during operation. If it has been stopped, turn
OFF/ON the power switch.
