Evolis Avansia Service Manual

Service Manual_AVA1_ENG-20220922_I 229
Ribbon Key Error 67-05
- If message occurs at early beginning of initialization, the initialization probably is a discrepancy
between printer zone and ribbon key zone.
- If message is displayed after ribbon check (initialization process), then it’s more likely discrepancy
between ribbon type and ribbon type value from the key.
- If initialization reached the end and message is displayed during printer usage, it could then be
generated by RFID tag/reader.
“Solutions” consist in having key tag closer to the reader:
- Key maintained as close as possible to reader thanks to bits of card inserted in key slot extra space.
- Tag removed from key and stuck to slot with scotch tape.

Evolis Avansia Specifications

General

Color	Yes
Card size	85.6 x 53.98 mm
Card types	Polycarbonate, PVC, PVC Composite
Print technology	Dye-sublimation/Resin Thermal transfer
Print speed (color)	144 card/h
Card thickness (min)	0.76 mm
Duplex print speed (color)	96 card/h
Display	LCD
Lamination	-
Certification	CE, FCC, UL, IEC RoHS
Product color	Black, White
Internal memory	64 MB
Cable lock slot type	Kensington
Total input capacity	250 sheets
Wi-Fi	No
Security algorithms	IPSEC
Ethernet interface type	Fast Ethernet
Bundled software	cardPresso XXS
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	297 mm
Width	340 mm
Height	436 mm
Weight	20000 g
