Service Manual_AVA1_ENG-20220922_I 147

Step 12 – OPTICAL SENSOR (SN9-SN12) – CP011847

1. Carry out step 9-1 to step 9-5 (page 130

2. Remove the two screws.

3. Open the cables holder.
