Evolis Avansia Service Manual

Service Manual_AVA1_ENG-20220922_I 79
SENSORS / MOTORS/ FANS/SWITCHES FONCTION LIST
Part
Part Description
Location
Function
SN1
Card sensor
Card feed (feeder)
Detection of card empty
SN2
Card Sensor (Cleaning
Assembly Outlet)
Card feed (flip turn)
Detection of the card (flip: cleaning
position)
SN3
Card Sensor (Reverse
Assembly Outlet)
Detection of the card (Flip section
position)
SN4
Card Sensor (Magnetic R/W)
Detection of the card (Magnetic Option
position)
SN5
Card Edging Sensor
(Secondary Transfer
Assembly)
Card feed (secondary
transfer)
Detection of the edge of the card
(Secondary transfer position)
SN6
Card Sensor (Ejection
Assembly Left)
Detection of the card (Transporting cards
position)
SN7
Reverse Assembly Position
Sensor 1
Card flip
Detection of the flip section position
SN8
Reverse Assembly Position
Sensor 2
Detection of the flip section position
SN9
Ribbon Beginning Sensor
Ink ribbon
Detection of the beginning of the ribbon
(ink ribbon mark)
SN10
Ribbon Feed Length Sensor
(Wind Up Axis)
Detection of the ribbon transport length
(used ribbon axis, DM1 pulses)
SN11
Ribbon Feed Length Sensor
(Supply Axis)
Detection of the ribbon transport length
(new ribbon axis, included in DM2)
SN12
Film Beginning Sensor 1
Transfer film
Detection of the beginning of the film
（1/2, transfer film mark）
SN13
Film Beginning Sensor 2
Detection of the beginning of the film
（
2/2, transfer film mark
）
SN14
Film Feed Length Sensor
(Supply Axis)
Detection of the film transport length
(new film axis, included in DM4)
SN15
Film Feed Length Sensor
(Wind Up Axis)
Detection of the film transport length
(used film axis, DM3 pulse)
SN16
Platen Position Sensor 1
Thermal head
Detection of the platen position
（
1/2
）
SN17
Platen Position Sensor 2
Detection of the platen position
（
2/2
）
SN18
Heat Roller Position Sensor 1
Heat roller
Detection of the heat roller position
（
1/2
）
SN19
Decurl Assembly Position
Sensor
Decurl
Detection of the de-curl position
SN20
Detection of the card
Card feed (flip turn)
Detection of the card (Only when the
option box is installed)
SN21
Detection of the edge of the
film
Only if the hologram
sensor is installed
Detection of the edge of the film
(hologram sensor)
SN22
Detection of the edge of the
film
Detection of the edge of the film (Only the
hologram sensor is installed)
SN23
Card Sensor (Ejection
Assembly Right)
Card feed (flip turn)
Detection of the card (Reject position)
SN24
Card Sensor (Cleaning
Assembly Inlet)
Card feed (feeder)
Detection of the card (Flip section
position)
SN25
Heat Roller Position Sensor 2
Heat roller
Detection of the heat roller position
（
2/2
）
SN26
Detection of the card
Card feed (flip turn)
Detection of the card (Only when the
contact IC R/W is installed)
MS1
Front Cover Switch
Else
Detection of open/close of the front
access cover (interlocking function)

Evolis Avansia Specifications

General

Color	Yes
Card size	85.6 x 53.98 mm
Card types	Polycarbonate, PVC, PVC Composite
Print technology	Dye-sublimation/Resin Thermal transfer
Print speed (color)	144 card/h
Card thickness (min)	0.76 mm
Duplex print speed (color)	96 card/h
Display	LCD
Lamination	-
Certification	CE, FCC, UL, IEC RoHS
Product color	Black, White
Internal memory	64 MB
Cable lock slot type	Kensington
Total input capacity	250 sheets
Wi-Fi	No
Security algorithms	IPSEC
Ethernet interface type	Fast Ethernet
Bundled software	cardPresso XXS
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	297 mm
Width	340 mm
Height	436 mm
Weight	20000 g
