Evolis Avansia Service Manual

Service Manual_AVA1_ENG-20220922_I 80
Part
Part Description
Location
Function
SW1
Power Switch
Chassis
Power on/power off
TM2
Heat Roller thermistor
Else
Detection of temperature (Heat roller)
TM3
Inner air thermistor
Detection of temperature (Inside air)
TM4
Outer air thermistor
Detection of temperature (Outside air)
TM5
Printhead thermistor
Detection of temperature (Thermal head)
PCB1
Main board
Chassis
Driving the printer
PCB2
Power Supply
Front cover
Powering the printer
PCB3
Operation Panel main board
Displays printer status, set functions,
adjustment
PCB4
RFID board
Chassis
Controls the type and consumed amount
of ink ribbon
DM1
Ribbon Wind Up Motor
Ink ribbon
Drives the ribbon take up mechanism
(Wind side, used ribbon axis)
DM2
Ribbon Supply Motor
Drives the ribbon take up mechanism
(Supply side, new ribbon axis)
DM3
Film Wind Up Motor
Transfer film
Drives the film take up mechanism (Wind
side, used ribbon axis)
DM4
Film Supply Motor
Drives the film take up mechanism
(Supply side, new ribbon axis)
DM5
Platen Lift Motor
Thermal head
Drives the platen elevation mechanism
DM6
Heat Roller Lift Motor
Heat roller
Drives the heat roller elevation
mechanism
DM7
Decurl Assembly Drive Motor
Decurl
Drives the de-curl mechanism
HB1
Card Feed Motor (Secondary
Transfer Assembly)
Card feed (secondary
transfer)
Drives the transporting cards mechanism
of printing
HB2
Film Feed Motor
Transfer film
Drives the transporting film mechanism
PM1
Card Supply Motor
Card feed (feeder)
Drives the feeding cards mechanism
PM2
Card Feed Motor (Reverse
Assembly)
Card flip
Drives the transporting cards mechanism
of flip section position
PM3
Reverse Assembly Rotation
Motor
Card feed (flip turn)
Drives the rotation mechanism of flip
section position
FAN1
Printhead Cooling Fan
Else
Cooling of the print head
FAN2
Power Supply PCB Cooling
Fan
Cooling of the power supply PCB
FAN3
Heat Roller Cooling Fan
Cooling of the heat roller mechanism
FAN4
Transfer Film Cooling Fan
Cooling of the transfer film

Evolis Avansia Specifications

General

Color	Yes
Card size	85.6 x 53.98 mm
Card types	Polycarbonate, PVC, PVC Composite
Print technology	Dye-sublimation/Resin Thermal transfer
Print speed (color)	144 card/h
Card thickness (min)	0.76 mm
Duplex print speed (color)	96 card/h
Display	LCD
Lamination	-
Certification	CE, FCC, UL, IEC RoHS
Product color	Black, White
Internal memory	64 MB
Cable lock slot type	Kensington
Total input capacity	250 sheets
Wi-Fi	No
Security algorithms	IPSEC
Ethernet interface type	Fast Ethernet
Bundled software	cardPresso XXS
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	297 mm
Width	340 mm
Height	436 mm
Weight	20000 g
