Service Manual_AVA1_ENG-20220922_I 29
Option mode List
Level 1
Level 2
Default values
Setting
Magnetic Encoder
Connection
DISCONNECT / CONNECT
Automatic
Coercivity
HIGH (HiCo) / LOW (LoCo)
Chip Port#1
Connection
DISCONNECT / CONNECT
Manual
Card Position
-20 to +15
Card Feed Test
Chip Port#2
Connection
DISCONNECT / CONNECT
Manual
Card Position
-20 to 0
External Box
Connection
DISCONNECT / CONNECT
Manual
Card Position
-20 to 0
RS-232C Setup
Baud Rate
9600 Bps / 19200 Bps / 38400 Bps
Data Bits
8 Bits / 7 Bits / 6 Bits
Parity bit
None / ODD / EVEN
Stop bits
1 bit / 2 bits
Answer Wait
0 to 100
Data Interval
0 to 10
