Service Manual_AVA1_ENG-20220922_I 130
Step 9 – HEAT ROLLER MODULE – S10248
1. Remove the ink ribbon and transfer film cassettes.
Basically, good practice for cassette handling consists in making sure cassette reference posts remain in
original position when storing or manipulating the cassettes.
OPPOSED TO
OR
2. Check that the heat roller is at the lower position.
3. Remove the four screws.
To Next Page
