Service Manual_AVA1_ENG-20220922_I 219

Cleaning rollers cleaning

1. Turn off the power.

2. Open the front cover

3. Remove the cleaning tape cassette (blue part).

4. Remove the cleaning tape cassette handle, lift it and pull.
