Evolis Avansia Service Manual

Service Manual_AVA1_ENG-20220922_I 35
ERROR CODE DETAILS
Code 01-01-to 3F-XX
Error Code
Item
Description
01-01
Error Message
Feeder empty
Outline
Card empty error (during card print reception)
Detection Description
The printer detected absence of cards in the card case during card print
reception.
Remedy
[Related parts]
• Harnesses from the Card Sensor (SN1) to the Main board
• Card Sensor (SN1)
• Main board
[Remedy]
1. Check if cards are properly loaded in the card case.
2. Check the reaction of the Card Sensor (SN1
) in the sensor check mode
of the service mode (page 27).
3. Check/replace the related harness/cable, connector and parts.
01-02
Error Message
Feeder empty
Outline
Card empty error (during standby)
Detection Description
The printer detected absence of cards in the card case during standby.
Remedy
[Related parts]
• Harnesses from the Card Sensor (SN1) to the Main board
• Card Sensor (SN1)
• Main board
[Remedy]
1. Check if cards are properly loaded in the card case.
2. Check the reaction of the Card Sensor (SN1
) in the sensor check mode
of the service mode (page 27).
3. Check/replace the related harness/cable, connector and parts.
04-01
Error Message
Cover open
Outline
Front access cover open error
Detection Description
The printer detected the front access cover open.
Remedy
[Related parts]
• Harnesses from the Front Cover Switch (MS1) to the Main board
• Front Cover Switch (MS1)
• Main board
[Remedy]
1. Close the front access cover.
2. Check the reaction of the Front Cover Switch (MS1
) in the sensor
check mode of the service mode (page 27).
3. Check/replace the related harness/cable, connector and parts.
05-01
Error Message
Cover open
Outline
Front access cover open error (during initialization)
Detection Description
The printer detected the front access cover open during initialization.
Remedy
[Related parts]
• Harnesses from the Front Cover Switch (MS1) to the Main board
• Front Cover Switch (MS1)
• Main board
[Remedy]
1. Close the front access cover.
2. Check the reaction of the Front Cover Switch (MS1
) in the sensor
check mode of the service mode (page 27).
3. Check/replace the related harness/cable, connector and parts.

Evolis Avansia Specifications

General

Color	Yes
Card size	85.6 x 53.98 mm
Card types	Polycarbonate, PVC, PVC Composite
Print technology	Dye-sublimation/Resin Thermal transfer
Print speed (color)	144 card/h
Card thickness (min)	0.76 mm
Duplex print speed (color)	96 card/h
Display	LCD
Lamination	-
Certification	CE, FCC, UL, IEC RoHS
Product color	Black, White
Internal memory	64 MB
Cable lock slot type	Kensington
Total input capacity	250 sheets
Wi-Fi	No
Security algorithms	IPSEC
Ethernet interface type	Fast Ethernet
Bundled software	cardPresso XXS
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	297 mm
Width	340 mm
Height	436 mm
Weight	20000 g
