Evolis Avansia Service Manual

Service Manual_AVA1_ENG-20220922_I 57
Code 40-XX to BF-01
Error Code
Item
Description
40-XX
Error Message
Call Tech Support
Outline
Reverse assembly rotation operation error
Detection Description
Rotation operation error of the reverse assembly was detected.
Remedy
[Related parts]
• Harnesses from the Reverse Assembly Position Sensor 1 (SN7) to the
Main board
• Harnesses from the Reverse Assembly Position Sensor 2 (SN8) to the
Main board
• Harnesses from the Reverse Assembly Rotation Motor (PM3) to the
Main board
• Reverse Assembly Position Sensor 1 (SN7)
• Reverse Assembly Position Sensor 2 (SN8)
• Reverse Assembly Rotation Motor (PM3)
• Main board
[Remedy]
1. Check the reaction of the Reverse Assembly Position Sensor 1 (SN7)
and the Re verse Assembly Position Sensor 2 (SN8) in the sensor
check mode of the service mode (page 27).
2. Check/replace the related harness/cable, connector and parts.
41-XX
Error Message
Call Tech Support
Outline
Primary transfer feed roller lift operation error
Detection Description
Lift operation error of the primary transfer feed roller was detected.
Remedy
[Related parts]
• Harnesses from the Platen Position Sensor 1 (SN16) to the Main board
• Harnesses from the Platen Position Sensor 2 (SN17) to the Main board
• Harnesses from the Platen Lift Motor (DM5) to the Main board
• Platen Position Sensor 1 (SN16)
• Platen Position Sensor 2 (SN17)
• Platen Lift Motor (DM5)
• Main board
[Remedy]
1. Check the reaction of the Platen Position Sensor 1 (SN16) and the
Platen Position Sensor 2 (SN17) in the sensor check mode of the
service mode (page 27).
2. Check/replace the related harness/cable, connector and parts.
42-XX
Error Message
Call Tech Support
Outline
Heat roller lift operation error
Detection Description
Lift operation error of the heat roller was detected.
Remedy
[Related parts]
• Harnesses from the Heat Roller Position Sensor 1 (SN18) to the Main
board
• Harnesses from the Heat Roller Position Sensor 2 (SN25) to the Main
board
• Harnesses from the Heat Roller Lift Motor (DM6) to the Main board
• Heat Roller Position Sensor 1 (SN18)
• Heat Roller Position Sensor 2 (SN25)
• Heat Roller Lift Motor (DM6)
• Main board
[Remedy]
1. Check the reaction of the Heat Roller Position Sensor 1 (SN18) and the
Heat Roller Position Sensor 2 (SN25) in the sensor check mode of the
service mode (page 27).
2. Check/replace the related harness/cable, connector and parts.

Evolis Avansia Specifications

General

Color	Yes
Card size	85.6 x 53.98 mm
Card types	Polycarbonate, PVC, PVC Composite
Print technology	Dye-sublimation/Resin Thermal transfer
Print speed (color)	144 card/h
Card thickness (min)	0.76 mm
Duplex print speed (color)	96 card/h
Display	LCD
Lamination	-
Certification	CE, FCC, UL, IEC RoHS
Product color	Black, White
Internal memory	64 MB
Cable lock slot type	Kensington
Total input capacity	250 sheets
Wi-Fi	No
Security algorithms	IPSEC
Ethernet interface type	Fast Ethernet
Bundled software	cardPresso XXS
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	297 mm
Width	340 mm
Height	436 mm
Weight	20000 g
