Evolis Avansia Service Manual

Service Manual_AVA1_ENG-20220922_I 58
Error Code
Item
Description
43-XX
Error Message
Call Tech Support
Outline
Decurl assembly lift operation error
Detection Description
Lift operation error of the decurl assembly was detected.
Remedy
[Related parts]
• Harnesses from the Decurl Assembly Position Sensor (SN19) to the
Main board
• Harnesses from the Decurl Assembly Drive Motor (DM7) to the Main
board
• Decurl Assembly Position Sensor (SN19)
• Decurl Assembly Drive Motor (DM7)
• Main board
[Remedy]
1. Check the reaction of the Decurl Assembly Position Sensor (SN19) in
the sensor check mode of the service mode (page 27).
2. Check/replace the related harness/cable, connector and parts.
50-XX
Error Message
Mag: Write Error
Outline
Magnetic data writing error
Detection Description
The writing of the magnetic data failed.
Remedy
[Related parts]
• Magnetic R/W Unit
[Remedy]
1. Check the setting direction of the magnetic card in the card case.
2. Check the magnetic card specifications.
⋅
ISO or JIS2
⋅
Hi-Co or Lo-Co
3. Check/replace the related harness/cable, connector and parts.
51-XX
Error Message
Mag: Read Error
Outline
Magnetic data reading error
Detection Description
The reading of the magnetic data failed.
Remedy
[Related parts]
• Magnetic R/W Unit
[Remedy]
1. Check the setting direction of the magnetic card in the card case.
2. Check the magnetic card specifications.
⋅
ISO or JIS2
⋅
Hi-Co or Lo-Co
3. Check/replace the related harness/cable, connector and parts.
52-XX
Error Message
Call Tech Support
Outline
Magnetic R/W unit communication error
Detection Description
The program error was detected.
Remedy
[Related parts]
• Magnetic R/W Unit
[Remedy]
1. Turn OFF/ON the power switch.
2. If this error occurs routinely, contact to the sales company.
53-XX
Error Message
Call Tech Support
Outline
Magnetic R/W unit communication error
Detection Description
Communication error between the printer and the magnetic R/W unit was
detected.
Remedy
[Related parts]
• Harnesses from the Magnetic R/W Unit to the Main board
• Magnetic R/W Unit
• Main board
[Remedy]
1. Check/replace the related harness/cable, connector and parts.

Evolis Avansia Specifications

General

Color	Yes
Card size	85.6 x 53.98 mm
Card types	Polycarbonate, PVC, PVC Composite
Print technology	Dye-sublimation/Resin Thermal transfer
Print speed (color)	144 card/h
Card thickness (min)	0.76 mm
Duplex print speed (color)	96 card/h
Display	LCD
Lamination	-
Certification	CE, FCC, UL, IEC RoHS
Product color	Black, White
Internal memory	64 MB
Cable lock slot type	Kensington
Total input capacity	250 sheets
Wi-Fi	No
Security algorithms	IPSEC
Ethernet interface type	Fast Ethernet
Bundled software	cardPresso XXS
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	297 mm
Width	340 mm
Height	436 mm
Weight	20000 g
