Evolis Avansia Service Manual

Service Manual_AVA1_ENG-20220922_I 213
4. Open the door and insert the tool.
5. Open the trapdoor cover. Tip over the decurl locker and lift the decurl module
6. By using the operation panel go to the service mode, then Action check (see
USING THE
OPERATION PANEL, page 22).
List of Action check used to clean the printer rollers:
Action Check
PM1: Card PM1: Forward Feeder Roller
PM2: Card
PM2: Forward
Flip over
PM2: Reverse
HB1: Card
HB1: Forward
Transport rollers
HB1: Reverse
HB2: Film
HB2: Forward
Film roller
HB2: Reverse
7. Select “HB1 Card “to clean the transport rollers.

Evolis Avansia Specifications

General

Color	Yes
Card size	85.6 x 53.98 mm
Card types	Polycarbonate, PVC, PVC Composite
Print technology	Dye-sublimation/Resin Thermal transfer
Print speed (color)	144 card/h
Card thickness (min)	0.76 mm
Duplex print speed (color)	96 card/h
Display	LCD
Lamination	-
Certification	CE, FCC, UL, IEC RoHS
Product color	Black, White
Internal memory	64 MB
Cable lock slot type	Kensington
Total input capacity	250 sheets
Wi-Fi	No
Security algorithms	IPSEC
Ethernet interface type	Fast Ethernet
Bundled software	cardPresso XXS
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	297 mm
Width	340 mm
Height	436 mm
Weight	20000 g
