Evolis Avansia Service Manual

Service Manual_AVA1_ENG-20220922_I 49
Error code
Item
Description
28-XX
Error Message
Flip Card Jam
Outline
Reverse assembly card jam error
Detection Description
The printer detected a card jam in the reverse assembly without the cards
on the card sensors (SN2/3/23/24).
Remedy
[Related parts]
• Harnesses from the Card Sensor (Cleaning Assembly Outlet) (SN2) to
the Main board
• Harnesses from the Card Sensor (Reverse Assembly Outlet) (SN3) to
the Main board
• Harnesses from the Card Sensor (Ejection Assembly Right) (SN23) to
the Main board
• Harnesses from the Card Sensor (Cleaning Assembly Inlet) (SN24) to
the Main board
• Harnesses from the Card Feed Motor (Reverse Assembly) (PM2) to
the Main board
• Card Sensor (Cleaning Assembly Outlet) (SN2)
• Card Sensor (Reverse Assembly Outlet) (SN3)
• Card Sensor (Ejection Assembly Right) (SN23)
• Card Sensor (Cleaning Assembly Inlet) (SN24)
• Card Feed Motor (Reverse Assembly) (PM2)
• Main board
[Remedy]
1. Check the reaction of the following sensors in the sensor check mode
of the service mode (page 27).
⋅
Card Sensor (Cleaning Assembly Outlet) (SN2
)
⋅
Card Sensor (Reverse Assembly Outlet) (SN3
)
⋅
Card Sensor (Ejection Assembly Right) (SN23
)
⋅
Card Sensor (Cleaning Assembly Inlet) (SN24
)
2. Check the reaction of the Card Feed Motor (Reverse Assembly) (PM2)
in the action check mode of the service mode (page 27). If it is
operating properly, clean the card feed roller.
3. Check/replace the related harness/cable, connector and parts.
2A-XX
Error Message
Remove Card: flip
Outline
Reverse assembly card jam error (multiple cards)
Detection Description
The printer detected multiple cards at the card sensors in the reverse
assembly.
Remedy
[Related parts]
• Harnesses from the Card Sensor (Cleaning Assembly Outlet) (SN2) to
the Main board
• Harnesses from the Card Sensor (Reverse Assembly Outlet) (SN3) to
the Main board
• Harnesses from the Card Sensor (Ejection Assembly Right) (SN23) to
the Main board
• Harnesses from the Card Sensor (Cleaning Assembly Inlet) (SN24) to
the Main board
• Card Sensor (Cleaning Assembly Outlet) (SN2)
• Card Sensor (Reverse Assembly Outlet) (SN3)
• Card Sensor (Ejection Assembly Right) (SN23)
• Card Sensor (Cleaning Assembly Inlet) (SN24)
• Main board
[Remedy]
1. Check the reaction of the following sensors in the sensor check mode
of the service mode (page 27).
⋅
Card Sensor (Cleaning Assembly Outlet) (SN2
)
⋅
Card Sensor (Reverse Assembly Outlet) (SN3
)
⋅
Card Sensor (Ejection Assembly Right) (SN23
)
⋅
Card Sensor (Cleaning Assembly Inlet) (SN24
)
2. Check/replace the related harness/cable, connector and parts.

Evolis Avansia Specifications

General

Color	Yes
Card size	85.6 x 53.98 mm
Card types	Polycarbonate, PVC, PVC Composite
Print technology	Dye-sublimation/Resin Thermal transfer
Print speed (color)	144 card/h
Card thickness (min)	0.76 mm
Duplex print speed (color)	96 card/h
Display	LCD
Lamination	-
Certification	CE, FCC, UL, IEC RoHS
Product color	Black, White
Internal memory	64 MB
Cable lock slot type	Kensington
Total input capacity	250 sheets
Wi-Fi	No
Security algorithms	IPSEC
Ethernet interface type	Fast Ethernet
Bundled software	cardPresso XXS
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	297 mm
Width	340 mm
Height	436 mm
Weight	20000 g
