Foundry Switch and Router Installation and Configuration Guide
15 - 106 December 2000
3. Select the ARP Cache
link to display the ARP cache.
This display shows the following information.
Displaying IP Traffic Statistics
To display IP traffic statistics on a Layer 2 Switch, use one of the following methods.
USING THE CLI
To display IP traffic statistics, enter the following command at any CLI level:
FastIron# show ip traffic
IP Statistics
27 received, 24 sent
0 fragmented, 0 reassembled, 0 bad header
0 no route, 0 unknown proto, 0 no buffer, 0 other errors
ICMP Statistics
Received:
0 total, 0 errors, 0 unreachable, 0 time exceed
0 parameter, 0 source quench, 0 redirect, 0 echo,
0 echo reply, 0 timestamp, 0 timestamp rely, 0 addr mask
0 addr mask reply, 0 irdp advertisement, 0 irdp solicitation
Sent:
0 total, 0 errors, 0 unreachable, 0 time exceed
0 parameter, 0 source quench, 0 redirect, 0 echo,
0 echo reply, 0 timestamp, 0 timestamp rely, 0 addr mask
0 addr mask reply, 0 irdp advertisement, 0 irdp solicitation
UDP Statistics
0 received, 0 sent, 0 no port, 0 input errors
TCP Statistics
1 current active tcbs, 4 tcbs allocated, 0 tcbs freed 0 tcbs protected
0 active opens, 0 passive opens, 0 failed attempts
0 active resets, 0 passive resets, 0 input errors
27 in segments, 24 out segments, 0 retransmission
Syntax: show ip traffic
Table 15.21: Web Display of ARP Cache – Layer 2 Switch
This Field... Displays...
Node The IP address of the device.
MAC Address The MAC address of the device.
Type The type, which is always Dynamic on Foundry Layer 2 Switches.
The device learns dynamic entries from incoming packet.
Age The number of minutes the entry has remained unused. If this value
reaches the ARP aging period, the entry is removed from the cache.
Port The port on which the entry was learned.
