Displaying OSPF Interface Information
To display OSPF interface information for the router, use one of the following methods.
USING THE CLI
To display OSPF interface information, enter the following command at any CLI level:
BigIron> show ip ospf interface
Syntax: show ip ospf interface [<ip-addr>]
The <ip-addr> parameter displays the OSPF interface information for the specified IP address.
USING THE WEB MANAGEMENT INTERFACE
1. Log on to the device using a valid user name and password for read-only or read-write access. The System
configuration panel is displayed.
2. Click on the plus sign next to Monitor in the tree view to expand the list of monitoring options.
3. Click on the plus sign next to OSPF in the tree view to expand the list of OSPF option links.
4. Click on the Interface
link.
Displaying OSPF Route Information
To display OSPF route information for the router, use one of the following methods.
USING THE CLI
To display OSPF route information, enter the following command at any CLI level:
BigIron> show ip ospf routes
Index Destination Mask Path_Cost Type2_Cost Path_Type
1 212.95.7.0 255.255.255.0 1 0 Intra
Adv_Router Link_State Dest_Type State Tag Flags
173.35.1.220 212.95.7.251 Network Valid 00000000 7000
Paths Out_Port Next_Hop Type Arp_Index State
1 5/6 209.95.7.250 OSPF 8 84 00
Index Destination Mask Path_Cost Type2_Cost Path_Type
2 11.3.63.0 255.255.255.0 11 0 Inter
Adv_Router Link_State Dest_Type State Tag Flags
209.95.7.250 11.3.63.0 Network Valid 00000000 0000
Paths Out_Port Next_Hop Type Arp_Index State
1 5/6 209.95.7.250 OSPF 8 84 00
Syntax: show ip ospf routes [<ip-addr>]
The <ip-addr> parameter specifies a destination IP address. If you use this parameter, only the route entries for
that destination are shown.
This display shows the following information.
Table 17.4: CLI Display of OSPF Route Information
This Field... Displays...
Index The row number of the entry in the router’s OSPF route table.
Destination The IP address of the route's destination.
Mask The network mask for the route.
Path_Cost The cost of this route path. (A route can have multiple paths. Each
path represents a different exit port for the Layer 3 Switch.)
