17 - 38 December 2000
• virtual-interface-receive-bad-packet-trap [MIB object: ospfVirtIfRxBadPacket]
• interface-retransmit-packet-trap [MIB object: ospfTxRetransmit]
• virtual-interface-retransmit-packet-trap [MIB object: ospfVirtIfTxRetransmit]
• originate-lsa-trap [MIB object: ospfOriginateLsa]
• originate-maxage-lsa-trap [MIB object: ospfMaxAgeLsa]
• link-state-database-overflow-trap [MIB object: ospfLsdbOverflow]
• link-state-database-approaching-overflow-trap [MIB object: ospfLsdbApproachingOverflow
EXAMPLE:
To stop an OSPF trap from being collected, use the CLI command: no trap <ospf-trap>, at the Router OSPF level
of the CLI. To disable reporting of the neighbor-state-change-trap, enter the following command:
BigIron(config-ospf-router)# no trap neighbor-state-change-trap
EXAMPLE:
To reinstate the trap, enter the following command:
BigIron(config-ospf-router)# trap neighbor-state-change-trap
Syntax: [no] snmp-server trap ospf <ospf-trap>
USING THE WEB MANAGEMENT INTERFACE
To disable a specific OSPF trap or traps:
1. Log on to the device using a valid user name and password for read-write access. The System configuration
panel is displayed.
2. Click on the plus sign next to Configure in the tree view to expand the list of configuration options.
3. Click on the plus sign next to OSPF in the tree view to expand the list of OSPF option links.
4. Click on the Trap
link to display the OSPF Trap panel.
5. Select the Disable radio button beside each OSPF trap you want to disable.
6. Click the Apply button to save the change to the device’s running-config file.
7. Select the Save
link at the bottom of the dialog. Select Yes when prompted to save the configuration change
to the startup-config file on the device’s flash memory.
Modify OSPF Standard Compliance Setting
Foundry routers are configured, by default, to be compliant with the RFC 1583 OSPF V2 specification.
USING THE CLI
To configure a router to operate with the latest OSPF standard, RFC 2178, enter the following commands:
BigIron(config)# router ospf
BigIron(config-ospf-router)# no rfc1583-compatibility
Syntax: [no] rfc1583-compatibility
USING THE WEB MANAGEMENT INTERFACE
To configure a router to operate with the latest OSPF standard, RFC 2178:
1. Log on to the device using a valid user name and password for read-write access. The System configuration
panel is displayed.
2. Click on the plus sign next to Configure in the tree view to expand the list of configuration options.
3. Click on the plus sign next to OSPF in the tree view to expand the list of OSPF option links.
4. Click on the General
link to display the OSPF configuration panel.
