Foundry Switch and Router Installation and Configuration Guide
17 - 44 December 2000
USING THE WEB MANAGEMENT INTERFACE
1. Log on to the device using a valid user name and password for read-only or read-write access. The System
configuration panel is displayed.
2. Click on the plus sign next to Monitor in the tree view to expand the list of monitoring options.
3. Click on the plus sign next to OSPF in the tree view to expand the list of OSPF option links.
4. Click on the Area
link.
Displaying OSPF Neighbor Information
To display OSPF neighbor information for the router, use one of the following methods.
USING THE CLI
To display OSPF neighbor information, enter the following command at any CLI level:
BigIron> show ip ospf neighbor
Port Address Pri State Neigh Address Neigh ID Ev Opt Cnt
8 212.76.7.251 1 full 212.76.7.200 173.35.1.220 23 2 0
Syntax: show ip ospf neighbor [router-id <ip-addr>] | [<num>]
The router-id <ip-addr> parameter displays only the neighbor entries for the specified router.
The <num> parameter displays only the entry in the specified index position in the neighbor table. For example, if
you enter “1”, only the first entry in the table is displayed.
This display shows the following information.
Cost The area’s cost.
SPFR The SPFR value.
ABR The ABR number.
ASBR The ABSR number.
LSA The LSA number.
Chksum(Hex) The checksum for the LSA packet. The checksum is based on all the
fields in the packet except the age field. The Layer 3 Switch uses the
checksum to verify that the packet is not corrupted.
Table 17.3: CLI Display of OSPF Neighbor Information
Field Description
Port The port through which the Layer 3 Switch is connected to the neighbor.
Address The IP address of this Layer 3 Switch’s interface with the neighbor.
Pri The OSPF priority of the neighbor. The priority is used during election of the Designated
Router (DR) and Backup designated Router (BDR).
Table 17.2: CLI Display of OSPF Area Information (Continued)
This Field... Displays...
