Foundry Networks Switch and Router User Manual

Foundry Switch and Router Installation and Configuration Guide
25 - 34 December 2000
NetIron-C(config-vlan-ipx-network)# other-proto name block-other-protocols
NetIron-C(config-vlan-other-proto)# exclude e9 to 16
NetIron-C(config-vlan-other-proto)# no dynamic
NetIron-C(config-vlan-other-proto)# interface ve 3
NetIron-C(config-vif-3)# ip addr 1.1.10.1/24
NetIron-C(config-vif-3)# ip ospf area 0.0.0.0
NetIron-C(config-vif-3)# int ve4
NetIron-C(config-vif-4)# ipx network 10 ethernet_802.3
NetIron-C(config-vif-4)# vlan 4 name Bridged_ALL_Protocols
NetIron-C(config-vlan-4)# untag ethernet 17 to 24
NetIron-C(config-vlan-4)# tag ethernet 25 to 26
NetIron-C(config-vlan-4)# spanning-tree
NetIron-C(config-vlan-4)# vlan 7 name Rtr_BB_to_Bldg.2
NetIron-C(config-vlan-7)# tag e25
NetIron-C(config-vlan-7)# no spanning-tree
NetIron-C(config-vlan-7)# router-interface ve5
NetIron-C(config-vlan-7)# vlan 6 name Rtr_BB_to_Bldg.1
NetIron-C(config-vlan-6)# tag ethernet 26
NetIron-C(config-vlan-6)# no spanning-tree
NetIron-C(config-vlan-6)# router-interface ve6
NetIron-C(config-vlan-6)# int ve5
NetIron-C(config-vif-5)# ip addr 1.1.8.2/24
NetIron-C(config-vif-5)# ip ospf area 0.0.0.0
NetIron-C(config-vif-5)# ipx network 8 ethernet_802.3
NetIron-C(config-vif-5)# int ve6
NetIron-C(config-vif-6)# ip addr 1.1.5.2/24
NetIron-C(config-vif-6)# ip ospf area 0.0.0.0
NetIron-C(config-vif-6)# ipx network 5 ethernet_802.3
NetIron-C(config-vif-6)#
Configuring AppleTalk Cable VLANs
You can configure up to eight AppleTalk cable VLANs within a port-based VLAN.
NOTE: This feature applies only to Chassis Layer 3 Switches and the TurboIron/8.
To configure an AppleTalk cable VLAN, you create a port-based VLAN, then create up to eight cable VLANs within
the port-based VLAN. You create the AppleTalk cable VLAN by assigning a number to the VLAN, optionally
naming the cable VLAN, assigning ports from the port-based VLAN, and specifying the router interface (virtual
interface) on which the Layer 3 Switch will send and receive traffic for the cable VLAN.
All the ports in an AppleTalk cable VLAN are within the same AppleTalk cable range. The device switches traffic
within the VLAN and routes traffic between VLANs.
Configuration Guidelines
Use the following guidelines when configuring AppleTalk cable VLANs:
• Up to eight AppleTalk cable VLANs are supported in a protocol-based VLAN. Each VLAN must be numbered
from 1 – 8.
• Each AppleTalk cable VLAN can have only one router interface. The router interface must be a virtual
interface.
• The AppleTalk cable VLANs cannot overlap. Thus, you cannot use the same port in more than one AppleTalk
cable VLAN.
• You must add the ports to the AppleTalk cable VLAN using the static option. You cannot use the dynamic or
exclude options.
• You cannot have an AppleTalk cable VLAN and an AppleTalk protocol VLAN in the same port-based VLAN. If
