Configuring OSPF
December 2000 17 - 47
Type2_Cost The type 2 cost of this path.
Path_Type The type of path, which can be one of the following:
• Inter – The path to the destination passes into another area.
• Intra – The path to the destination is entirely within the local
area.
• External1 – The path to the destination is a type 1 external
route.
• External2 – The path to the destination is a type 2 external
route.
Adv_Router The OSPF router that advertised the route to this Foundry Layer 3
Switch.
Link-State The link state from which the route was calculated.
Dest_Type The destination type, which can be one of the following:
• ABR – Area Border Router
• ASBR – Autonomous System Boundary Router
• Network – the network
State The route state, which can be one of the following:
• Changed
• Invalid
• Valid
This information is used by Foundry technical support.
Tag The external route tag.
Flags State information for the route entry. This information is used by
Foundry technical support.
Paths The number of paths to the destination.
Out_Port The router port through which the Layer 3 Switch reaches the next
hop for this route path.
Next_Hop The IP address of the next-hop router for this path.
Type The route type, which can be one of the following:
• OSPF
• Static Replaced by OSPF
Arp_Index The index position in the ARP table of the ARP entry for this path's IP
address.
State State information for the path. This information is used by Foundry
technical support.
Table 17.4: CLI Display of OSPF Route Information (Continued)
This Field... Displays...
