2 - 32 December 2000
NOTE: If the slot has never contained a module or you are swapping in exactly the same type of module, you do
not need to use the module command. The slot requires configuration only if it has already been configured for
another type of module.
USING THE CLI
To add a module to a Chassis device:
BigIron(config)# module 3 bi-8-port-gig-management-module
Syntax: module <slot-num> <module-type>
The <slot-num> parameter indicates the chassis slot number.
The <module-type> parameter specifies the platform, module type, and port configuration of the module.
NOTE: Module options that begin with “bi” and are for the Management IV module also are applicable to the
NetIron Internet Backbone router.
USING THE WEB MANAGEMENT INTERFACE
To configure a chassis slot for a module:
1. Log on to the device using a valid user name and password for read-write access. The System configuration
panel is displayed.
2. Click on the Module
link to display the Module panel, as shown in the following example.
3. Click the Add Module
link to display the following panel.
