Foundry Switch and Router Installation and Configuration Guide
19 - 94 December 2000
USING THE WEB MANAGEMENT INTERFACE
You cannot display summary neighbor information using the Web management interface.
NLRIs Discarded due to Indicates the number of times the Layer 3 Switch discarded an NLRI
for the neighbor due to the following reasons:
• Maximum Prefix Limit – The Layer 3 Switch’s configured
maximum prefix amount had been reached.
• AS Loop – An AS loop occurred. An AS loop occurs when the
BGP4 AS-path attribute contains the local AS number.
• Invalid Nexthop – The next hop value was not acceptable.
• Duplicated Originator_ID – The originator ID was the same as the
local router ID.
• Cluster_ID – The cluster list contained the local cluster ID, or
contained the local router ID (see above) if the cluster ID is not
configured.
Routes Advertised The number of routes the Layer 3 Switch has advertised to this
neighbor.
• To be Sent – The number of routes the Layer 3 Switch has
queued to send to this neighbor.
• To be Withdrawn – The number of NLRIs for withdrawing routes
the Layer 3 Switch has queued up to send to this neighbor in
UPDATE messages.
NLRIs Sent in Update Message The number of NLRIs for new routes the Layer 3 Switch has sent to
this neighbor in UPDATE messages.
• Withdraws – The number of routes the Layer 3 Switch has sent to
the neighbor to withdraw.
• Replacements – The number of routes the Layer 3 Switch has
sent to the neighbor to replace routes the neighbor already has.
Peer Out of Memory Count for Statistics for the times the Layer 3 Switch has run out of BGP4
memory for the neighbor during the current BGP4 session.
• Receiving Update Messages – The number of times UPDATE
messages were discarded because there was no memory for
attribute entries.
• Accepting Routes(NLRI) – The number of NLRIs discarded
because there was no memory for NLRI entries. This count is not
included in the Receiving Update Messages count.
• Attributes – The number of times there was no memory for BGP4
attribute entries.
• Outbound Routes(RIB-out) – The number of times there was no
memory to place a “best” route into the neighbor's route
information base (Adj-RIB-Out) for routes to be advertised.
Table 19.5: BGP4 Route Summary Information for a Neighbor (Continued)
This Field... Displays...
