The procedure to set iSCSI port parameters is as follows:
1 Select which iSCSI port to set the parameters for (multiple selections can be
made) and click [Set iSCSI Port Parameters] in [Action].
2 Set the parameters for all of the selected ports and click the [Set] button.
The settings of port parameters vary depending on the port type and the port mode.
■ When the port mode is "CA"
When the type is "1G-iSCSI" or "10G-iSCSI" and the port mode is "CA", specify the
following items:
● Select Port
• Port
Select the target port or select the copy source port.
The location options for the selected port are displayed:
- CM#x CA#y Port#z (x: CM number, y: CA number, z: Port number)
● TCP/IP Settings
• IP Address
Enter the IP address of the target port (required).
Click the [Test Connection (ping)] button to display the "[Send Ping Command] Screen"
(page 367). Specify the IP address to check the connection status of the connection
destination device and the number of transmissions. Click the [Send] button. When the
"ping" command is sent, the settings of the IP address and the connection path for the
destination device can be checked.
The following input conditions apply:
- 1 - 3 numeric characters
- First text box: "1" - "255"
- Other text box: "0" - "255"
• Subnet Mask
Enter the subnet mask of the target port (required).
The following input conditions apply:
- 1 - 3 numeric characters
- All text boxes: "0" - "255"
• Default Gateway
Enter the default gateway IP address of the target port.
- 1 - 3 numeric characters
- All text boxes: "0" - "255"
The same port mode can be selected for multiple "1G-iSCSI" or
"10G-iSCSI" type iSCSI ports. Multiple selections can also be made
for the "iSCSI-RA (for the connection of older devices)" type iSCSI
ports.
When multiple ports are selected, select the target port and set the
parameters for each port.
