Chapter 9 Connectivity Management
9.2 Functions in the Action Area for Connectivity
ETERNUS Web GUI User’s Guide
359
Copyright 2011 FUJITSU LIMITED P2X0-1090-02ENZ0
• TCP Port No.
Enter the TCP port number of the target port between 0 and 28671.
Click the [Default] button to set the default TCP port number.
• TCP Window Scale
Select the TCP Window scale of the target port between 0 and 14.
"TCP Window Scale" is a parameter that is used to specify the TCP window size.
Specify the "TCP Window Scale" in powers of two.
The relationship between the setting value and the TCP Window Scale is as follows:
• iSNS Server
Select whether to use the iSNS server in the target port.
When "Enable" is selected, enter the IP address of the iSNS server.
Internet Storage Name Service (iSNS) is almost equivalent to Domain Name System
(DNS) for the Internet. iSNS server is used to convert the iSCSI name to the IP address
on the iSCSI network.
The following input conditions apply:
- 1 - 3 numeric characters
- All text boxes: "0" - "255"
• iSNS Server Port No.
When "Enable" is selected to use the iSNS server for the target port, specify between 0
and 65535 for the port number of the iSNS server.
Click the [Default] button to set the default iSNS server port number.
● iSCSI Settings
• iSCSI Name
Enter the iSCSI name of the target port.
Click the [Default] button to set the default iSCSI name.
The following input conditions apply:
- Alphabetic characters (lower case) and numeric characters
- Symbols "-"(hyphen), "." (period) and ":"(colon)
- The name starts with "jpn." or "eui."
- Up to 223 characters
TCP Window Scale TCP Window size
0 32 KB
1 64 KB
2 128 KB
3 256 KB
4 512 KB
5 1024 KB
6 2048 KB
7 4096 KB
8 8192 KB
9 16384 KB
10 32768 KB
11 65536 KB
12 131072 KB
13 262144 KB
14 524288 KB
