■ When the type is "iSCSI-RA (for the connection of older devices)"
When the type is "iSCSI-RA (for the connection of older devices)", specify the following
items:
● Port Settings
• Port
Select the target port or select the copy source port.
The location options for the selected port are displayed:
- CM#x CA#y Port#z (x: CM number, y: CA number, z: Port number)
● TCP/IP Settings
• IP Address
Enter the IP address of the target port (required).
Click the [Test Connection (ping)] button to display the "[Send Ping Command] Screen"
(page 367). Specify the IP address to check the connection status of the connection
destination device and the number of transmissions. Click the [Send] button. When the
"ping" command is sent, the settings of the IP address and the connection path for the
destination device can be checked.
The following input conditions apply:
- 1 - 3 numeric characters
- First text box: "1" - "255"
- Other text box: "0" - "255"
• Subnet Mask
Enter the subnet mask of the target port (required).
The following input conditions apply:
- 1 - 3 numeric characters
- All text boxes: "0" - "255"
• Default Gateway
Enter the default gateway IP address of the target port.
- 1 - 3 numeric characters
- All text boxes: "0" - "255"
● iSCSI Settings
• iSCSI Name
Enter the iSCSI name of the target port.
Click the [Default] button to set the default iSCSI name.
The following input conditions apply:
- Alphabetic characters (lower case) and numeric characters
- Symbols "-"(hyphen), "." (period) and ":"(colon)
- The name starts with "jpn." or "eui."
- Up to 223 characters
An iSCSI name is a unique name in the ETERNUS DX Disk
storage system. The same iSCSI name cannot be set to multiple
iSCSI ports except the device iSCSI name.
