Chapter 10 Component Management
10.1 Component Status
ETERNUS Web GUI User’s Guide
411
Copyright 2011 FUJITSU LIMITED P2X0-1090-02ENZ0
The following items are displayed in the Main area:
• Enclosure
The enclosure where the drive is installed is displayed.
• Slot No.
The slot number of the enclosure where the drive is installed is displayed. By clicking the drive
image, the [Disks] screen is displayed. Refer to "10.1.11 Disks Detail" (page 427)
for display
items.
• Status
The drive status is displayed. Refer to "B.5 Component Status" (page 615)
for details.
• Capacity
The capacity of the drive is displayed.
• Speed
The drive speed is displayed. For SSD, "0 rpm" is displayed.
- 15000 rpm
- 10000 rpm
- 7200 rpm
- 0 rpm
• Type
The drive type is displayed.
- For 2.5-inch SAS disks: 2.5" Online
- For 3.5-inch SAS disks: 3.5" Online
- For 3.5-inch Nearline SAS disks: 3.5" Nearline
- For 2.5-inch SSD: 2.5" SSD
- For 3.5-inch SSD: 3.5" SSD
• Usage
The usage of the drive is displayed.
- Disk
- Data
- Unused
- System
- Global Hot Spare
- Dedicated Hot Spare
• RAID Group
If the drive is registered in a RAID group, the RAID group name to which the drive belongs is
displayed.
By clicking this item, the [RAID Group] screen is displayed.
The RAID group name cannot be clicked when logged on via a Slave CM.
