6-18 SPARC Enterprise M4000/M5000 Servers Service Manual • December 2010
6.2.6 Accessing the CD-RW/DVD-RW Drive Backplane
of the M4000 Server
Caution – There is an electrical hazard if the power cords are not disconnected. All
power cords must be disconnected to completely remove power from the server.
Caution – Use proper ESD grounding techniques when handling components. See
Section 1.1, “Safety Precautions” on page 1-1.
1. Power off the server.
This step includes turning the key switch to the Service position, confirming that
the POWER LED is off, and disconnecting power cables. See Section 4.4.1,
“Powering the Server Off Using Software” on page 4-12.
Caution – To prevent the equipment rack from tipping over, you must deploy the
antitilt feature, if applicable, before you slide the server out of the equipment rack.
Note – When drawing out the SPARC Enterprise M4000/M5000 Server to the front,
release the cable tie holding the PCI cables on the rear of the server.
2. Remove the fan cover.
This step includes deploying the rack’s antitilt features (if applicable), sliding the
server out of the equipment rack, removing the 60-mm fan units and removing the
fan cover. See Section 5.3.1, “Removing the Fan Cover” on page 5-8.
6.2.7 Removing the CD-RW/DVD-RW Drive Backplane
of the M4000 Server
1. Remove the CD-RW/DVD-RW Drive Unit from the server and place it on the
ESD mat.
See Section 6.2.3, “Removing the CD-RW/DVD-RW Drive Unit” on page 6-16.
2. Remove the power and serial cables from the rear of the CD-RW/DVD-RW
Drive Backplane.
