6-4 SPARC Enterprise M4000/M5000 Servers Service Manual • December 2010
6.1.1 Accessing the Hard Disk Drive
Note – If the hard disk drive is the boot device, the hard disk will have to be
replaced using cold replacement procedures. However, active replacement can be
used if the boot disk can be isolated from the Oracle Solaris OS by disk mirroring
software and other software. See Section 4.4, “Cold Replacement (Powering the
Server Off and On)” on page 4-12.
● Remove the hard disk drive from the domain.
This step includes using the cfgadm command to determine the Ap_Id and
disconnecting the hard disk drive. See Section 4.2.1, “Removing a FRU From a
Domain” on page 4-4.
6.1.2 Removing the Hard Disk Drive
Caution – Use proper ESD grounding techniques when handling components. See
Section 1.1, “Safety Precautions” on page 1-1.
1. Push the button on the front of the hard disk drive to release the drive latch
(
FIGURE 6-3).
2. Pull the latch so that it is straight out from the hard disk drive to unseat the
drive.
3. Remove the hard disk drive and place it on the ESD mat.
FIGURE 6-3 Removing the Hard Disk Drive
