10-6 SPARC Enterprise M4000/M5000 Servers Service Manual • December 2010
10.1.3 Installing the 60-mm Fan Module
Caution – Do not force the fan into the slot. Doing so can cause damage to the fan
and server.
1. Align the fan module (LED on left) and slide the fan into the slot.
A fan module placed backwards into the slot will stop halfway to prevent damage
to the connectors. If the fan does not slide in easily, remove it, and rotate the fan
180 degrees and then try again.
2. Push down with two fingers to seat the fan module.
10.1.4 Securing the Server
● Slide the server into the equipment rack and secure the stabilizer bar.
See Section 5.1.2, “Sliding the Server Into the Equipment Rack” on page 5-4.
