Appendix C FRU List C-7
Refer to Section 8.3, “I/O Unit Replacement” on page 8-10 for replacement
procedures.
C.5 Power
Power is provided to both midrange servers by power supply units. The redundant
power supplies allow continued system operation if a power supply fails.
TABLE C-5
lists the power supply features and specifications.
TABLE C-4 PCI-Express (PCIe) and PCI-eXtended (PCI-X) Features
PCI-Express (PCIe) Features PCI eXtended (PCI-X) Features
• High-speed serial, point-to-point
interconnect.
• Expands and doubles the data transfer
rates compared with the original PCI.
• Faster version of the parallel bus PCI
standard.
• PCI-X bus has improved protocols and a
faster clock rate compared with the parallel
bus PCI standard.
TABLE C-5 Power Supply Features
M4000 Ser ver M5000 Ser ver
Number of power cords
1 power cord per power supply unit
2 power cords are required for
redundancy
1 power cord per power supply unit
4 power cords are required for
redundancy
Redundancy
1 + 1 redundant
Second power supply is redundant at
200 VAC
2 + 2 redundant
Second and fourth power supplies are
redundant at 200 VAC
Active replacement capability
Yes Yes
Hot replacement capability
Yes Yes
Cold replacement capability
Yes (from front) Yes (from front)
Redundant AC input
Yes Yes
Input voltage
100–127 VAC
200–240 VAC
100–127 VAC
200–240 VAC
Frequency
50–60 Hz 50–60 Hz
Maximum current
24.0A at 100–127 VAC, (12A/cord)
12.0A at 200–240 VAC, (12A/cord)
48A at 100–127 VAC (12A/cord)
24A at 200–240 VAC (12A/cord)
