5-1
CHAPTER
5
Internal Components Access
This chapter describes how to access the internal components. The information is
organized into the following topics:
■ Section 5.1, “Sliding the Server In and Out to the Fan Stop” on page 5-1
■ Section 5.2, “Top Cover Remove and Replace” on page 5-5
■ Section 5.3, “Fan Cover Remove and Replace” on page 5-8
5.1 Sliding the Server In and Out to the Fan
Stop
The slide rails have two designated lock points. The first, the fan stop, is for easy
access to the fan units. The fan units are hot, active, or cold replacement components.
When using active replacement, only one fan unit should be replaced at a time to
ensure redundancy.
