10-16 SPARC Enterprise M4000/M5000 Servers Service Manual • December 2010
10.1.15 Installing the M4000 Server 172-mm Fan
Backplane
1. Slide the 172-mm fan backplane downwards towards the interior of the server
and then pull it forward into place.
2. Connect the cable to the 172-mm fan backplane.
3. Tighten the captive screw that secures the 172-mm fan backplane.
4. Install the fan cage and tighten the two (2) captive screws that secure it in place.
5. Install the 172-mm fan units.
See Section 10.1.7, “Installing the 172-mm Fan Module” on page 10-9.
10.1.16 Securing the Server
1. Slide the server into the equipment rack and secure the stabilizer bar.
See Section 5.1.2, “Sliding the Server Into the Equipment Rack” on page 5-4.
2. Power on the server.
This step includes reconnecting power cables, verifying the LEDs, and turning the
keyswitch to the Locked position. See Section 4.4.2, “Powering the Server On
Using Software” on page 4-13.
Note – If the Oracle Solaris automatic booting is set, use the sendbreak -d
domain_id command after the display console banner is displayed but before the
system starts booting the operating system to get the ok prompt.
3. Confirm the hardware.
This step includes running programs to be certain all components are mounted
again and then booting the operating system.
Refer to Section 4.3.2, “Verifying Hardware Operation” on page 4-9 for more
information.
