Chapter 10 Fan Modules Replacement 10-9
10.1.7 Installing the 172-mm Fan Module
Caution – Do not force the fan module into the slot. Doing so can cause damage to
the fan module and server.
1. Align the fan module (LED on left) and slide the fan into the slot.
A fan module placed backwards into the slot will stop halfway to prevent damage
to the connectors. If the fan does not slide in easily, remove it, and rotate the fan
180 degrees and then try again.
2. Push down with two fingers to seat the fan module.
10.1.8 Securing the Server
● Slide the server into the equipment rack and secure the stabilizer bar.
See Section 5.1.2, “Sliding the Server Into the Equipment Rack” on page 5-4.
