13-12 SPARC Enterprise M4000/M5000 Servers Service Manual • December 2010
13.2 DC-DC Converter Replacement
The DC-DC converters are cold replacement components. This means the entire
server must be powered off and the power cords disconnected to replace a DC-DC
converter.
FIGURE 13-5 shows the location of the DC-DC converter on the M4000 server.
FIGURE 13-5 M4000 Server DC-DC Converter Location
Location Number Component
1 DC-DC Converter (DDC_B#0) (with metal heatsink)
2 DC-DC Converter (DDC_A#0)
3 DC-DC Converter (DDC_A#1)
1
2
3
