Fujitsu SPARC Enterprise M5000 User Manual

6-1
CHAPTER
6
Storage Devices Replacement
This chapter describes how to remove and install the main storage systems. The
information is organized into the following topics:
■ Section 6.1, “Hard Disk Drive Replacement” on page 6-1
■ Section 6.2, “CD-RW/DVD-RW Drive Unit (DVDU) Replacement” on page 6-12
■ Section 6.3, “Tape Drive Unit Replacement” on page 6-23
6.1 Hard Disk Drive Replacement
Hard disk drives are active, hot, or cold replacement components. Hard disk drive
backplanes are cold replacement components. The hard disk drives are identical on
both midrange servers. Hard disk drives and hard disk drive backplane information
is organized into the following sections:
■ Section 6.1.1, “Accessing the Hard Disk Drive” on page 6-4
■ Section 6.1.2, “Removing the Hard Disk Drive” on page 6-4
■ Section 6.1.3, “Installing the Hard Disk Drive” on page 6-5
■ Section 6.1.4, “Securing the Server” on page 6-5
■ Section 6.1.5, “Accessing the Hard Disk Drive Backplane of the M4000 Server” on
page 6-6
■ Section 6.1.6, “Removing the Hard Disk Drive Backplane of the M4000 Server” on
page 6-6
■ Section 6.1.7, “Installing the Hard Disk Drive Backplane of the M4000 Server” on
page 6-7
■ Section 6.1.8, “Securing the Server” on page 6-8
■ Section 6.1.9, “Accessing the Hard Disk Drive Backplane of the M5000 Server” on
page 6-9
