Fujitsu SPARC Enterprise M5000 User Manual

Appendix E UPS Controller E-5
FIGURE E-2 Corresponding Terminals in UPC Port and the UPS Cable
Note – If you need UPC cables, you need to make arrangements separately. For
details, contact your sales representatives.
E.6 UPC Connector
This chapter describes the location of the UPC connector and the UPS connections.
■ UPC#0 connects with UPS#0. UPC#1 connects with UPS#1.
■ The single power feed uses UPC#0 only.
■ The dual power feed option uses UPC#0 and UPC#1.
Note: Do not use ER signal.
(Note)
*BTL
*BPS/*UALM
*ACOFF
SG
ER
UPC port side
UPS cable side
*BTL
*BPS/*UALM
*ACOFF
SG
1
2
3
4
5
6
7
8
9
Pin # Signal name
---
---
---
---
