Chapter 11 Memory Board Replacement 11-5
11.1.2 Removing the Memory Board
1. Pinch the handles together and pull both levers upwards simultaneously to
unseat the memory board.
Note – Keep track of the original Memory Board locations so that the boards can be
returned to the same locations.
2. Slide the memory board out of the server and place it on the ESD mat.
Caution – Do not stack more than four memory boards on top of one another.
FIGURE 11-3 Memory Board Removal
