13.1.7 Installing the M5000 Server Motherboard Unit
Caution – The motherboard is heavy. Two people are recommended to lift the unit.
Caution – Use proper ESD grounding techniques when handling components. See
Section 1.1, “Safety Precautions” on page 1-1.
1. Align the motherboard unit feet with the rails and lower the unit into the
server.
2. Push the motherboard unit handles down until they are horizontal to seat the
board.
3. Tighten the two (2) captive screws in the center of the motherboard unit to
secure the motherboard unit handles in place.
4. Secure the eight (8) bus bar screws at the front of the motherboard unit using a
magnetic screwdriver.
5. Install the two (2) CPU module baffles and secure them with the latches.
