Chapter 6 Storage Devices Replacement 6-33
6.3.12 Securing the Server
Caution – The motherboard unit is heavy. Two people are recommended to lift the
unit.
1. Install the motherboard unit.
This step includes installing the motherboard cradle, securing the busbar screws,
and installing the CPU modules and filler panels See Section 13.1.7, “Installing the
M5000 Server Motherboard Unit” on page 13-10.
2. Install the top cover.
This step includes sliding the server in to the equipment rack and restoring the
rack antitilt features to their original position. See Section 5.2.2, “Replacing the Top
Cover” on page 5-8.
3. Power the server on.
This step includes reconnecting power cables and turning the keyswitch to the
Locked position. See Section 4.4.2, “Powering the Server On Using Software” on
page 4-13.
Note – If the Oracle Solaris automatic booting is set, use the sendbreak -d
domain_id command after the display console banner is displayed but before the
system starts booting the operating system to get the ok prompt.
4. Confirm the hardware.
This step includes running programs to be certain all components are mounted
again and then booting the operating system.
Refer to Section 4.3.2, “Verifying Hardware Operation” on page 4-9 for more
information.
