6-22 SPARC Enterprise M4000/M5000 Servers Service Manual • December 2010
3. Connect the power and serial cables to the rear of the CD-RW/DVD-RW Drive
Backplane.
Caution – Do not force the CD-RW/DVD-RW Drive Unit into a slot. Doing so can
cause damage to the drive and server.
4. Install the CD-RW/DVD-RW Drive Unit.
See Section 6.2.4, “Installing the CD-RW/DVD-RW Drive Unit” on page 6-17.
6.2.13 Securing the Server
Caution – The motherboard unit is heavy. Two people are recommended to lift the
unit.
1. Install the motherboard unit.
This step includes installing the motherboard cradle, securing the busbar screws,
and installing the CPU modules and filler panels See Section 13.1.7, “Installing the
M5000 Server Motherboard Unit” on page 13-10.
2. Install the top cover.
This step includes sliding the server in to the equipment rack and restoring the
antitilt features to their original position. See Section 5.2.2, “Replacing the Top
Cover” on page 5-8.
3. Power the server on.
This step includes reconnecting power cables, verifying the state of the LEDs, and
turning the keyswitch to the Locked position. See Section 4.4.2, “Powering the
Server On Using Software” on page 4-13.
Note – If the Oracle Solaris automatic booting is set, use the sendbreak -d
domain_id command after the display console banner is displayed but before the
system starts booting the operating system to get the ok prompt.
4. Confirm the hardware.
This step includes running programs to be certain all components are mounted
again and then booting the operating system.
Refer to Section 4.3.2, “Verifying Hardware Operation” on page 4-9 for more
information.
