Fujitsu SPARC Enterprise M5000 User Manual

Chapter 6 Storage Devices Replacement 6-7
5. Remove all hard disk drives and place them on the ESD mat.
See Section 6.1.2, “Removing the Hard Disk Drive” on page 6-4.
6. Remove the power cable (p3) from the rear of the hard disk drive backplane.
7. Loosen the captive screw that holds the hard disk drive backplane in place.
8. Lift the hard disk drive backplane from the guide pins.
9. Remove the blue serial cable from the hard disk drive backplane and place the
backplane on the ESD mat.
6.1.7 Installing the Hard Disk Drive Backplane of the
M4000 Server
1. Secure the blue serial cable to the hard disk drive backplane.
2. Place the hard disk drive backplane onto the guide pins.
3. Tighten the captive screw that holds down the rear of the hard disk drive
backplane in place.
4. Secure the power cable (p3) to the rear of the hard disk drive backplane.
Caution – Do not force any components into server slots. Doing so can cause damage
to the component and server.
5. Install the hard disk drives.
See Section 6.1.3, “Installing the Hard Disk Drive” on page 6-5.
6. Place the CD-RW/DVD-RW backplane onto the guide pin.
7. Tighten the captive screw that holds the rear of the CD-RW/DVD-RW Drive
Backplane in place.
8. Connect the power and serial cables to the rear of the CD-RW/DVD-RW Drive
Backplane.
9. Install the CD-RW/DVD-RW Drive Unit.
See Section 6.2.4, “Installing the CD-RW/DVD-RW Drive Unit” on page 6-17.
