Chapter 6 Storage Devices Replacement 6-3
The following illustration shows the locations of the hard disk drives and the hard
disk drive backplane on the SPARC Enterprise M5000 server.
FIGURE 6-2 M5000 Server Hard Disk Drives and Hard Disk Drive Backplane Locations
Location Number Component
1 Hard disk drive backplane (HDDBP#1 IOU#1)
2 Hard disk drive backplane (HDDBP#0 IOU#0)
3 Hard disk drive (HDD#1)
4 Hard disk drive (HDD#0)
5 Hard disk drive (HDD#3)
6 Hard disk drive (HDD#2)
3
4
5
6
2
1
