Installing LCD
1. Remove filler plate from the back of LCD.
2. Connect cables from rotating arm to the correct port on LCD.
3. Make sure that all cables are routed under the LCD cable guide.
4. Attach LCD to the rotating arm bracket by using screws (4).
5. Replace filler plate.
5-62 Rev 3.0 90000291
TeamPoS 2000 MAINTENANCE MANUAL
Note: LCD monitors come with a protective film over the screen. Do not remove this film
until installation is complete to avoid accidental damage to the surface.
