90000291 Rev 3.0 5-37
TeamPoS 2000 MAINTENANCE MANUAL
5.9 Model D15 LCD Stands
The 15" Liquid Crystal Display (LCD) used with the TeamPoS 2000 is a TFT
technology and has both digital and analog interfaces and speakers. Options include
touch, keypad and MSR. Touch options are factory installed and cannot be field
installed. Built-in speakers are standard.
Model D15 Stands: two stands are available:
1. Stacked stand, for stacking the D15 with or without SmartPoSKeyPad options on a
control unit.
2. Dispersed stand, for dispersing the LCD with or without the SmartPoSKeyPad,
SmartPoSMSR options on a checkstand or counter.
3. A third mount is an in-counter mount which consists of a cable, a connector that
attaches to the LCD and an interface for connecting external cables (in development).
The following table summarizes the D15 LCD stands and options:
D15 non-touch D15 touch D15 w/MSR, w/keypad, or
w/keypad&MSR
Audio Yes Yes Yes
Touch No Yes Yes
Stacked Yes Yes Yes
Dispersed Yes Yes Yes
Kiosk NA NA NA
5.9.1 D15 LCD Cable Requirements
The following graphics show D15 LCD cable requirements for various configurations of
digital and analog LCDs. Refer to the cable summary at the end of these graphics for
cable part numbers.
5.9.2 D15 LCD Audio Cable Connections
Audio connections to the LCD are the same for digital as for analog. The audio cable plugs
