8.1.29 Configure Advanced Settings for SouthBridge - M Motherboard
In the Chipset Southbridge screen, scroll down to see additional settings.
BIOS SETUP UTILITY VXX.xx
Main Advanced PCIPnP Boot Security Chipset Power
Other
Configure advanced settings for SouthBridge
ICH4 Dev31 Func1, IDE [Enabled]
Instructions will appear
ICH4 Dev31 Func3, SMBUS [Enabled]
in this part of the screen
ICH4 Dev31 Func5, AC'97 [Enabled]
ICH4 Dev29 Func0, USB#1 [Enabled]
ICH4 Dev29 Func1, USB#2 [Enabled]
ICH4 Dev29 Func2, USB#3 [Enabled]
ICH4 Dev29 Func7, EHCI [Enabled]
Sound Blaster Decode [Disabled]
¬ ® Select Screen
Microsoft Sound Decode [Disabled]
¯ Select Item
MIDI Decode [Disabled]
+ - Change Field
Adlib Range 388h-38Bh [Enabled] Tab Select Field
LPC 4Eh-4Fh Decode [Enabled] F1 General Help
LPC 2Eh-2Fh Decode [Enabled] F10 Save and Exit
ESC Exit
Onboard LAN [Enabled]
Usage of LAN Option ROM [Enabled]
IOAPIC [Disabled]
Extended IOAPIC [Disabled]
CPU B.I.S.T. [Enabled]
ICH4 DMA Collection [Enabled]
PC/PCIB Select [Disabled]
DMA-0 Type [LPC DMA]
DMA-1 Type [LPC DMA]
DMA-2 Type [LPC DMA]
DMA-3 Type [LPC DMA]
90000291 Rev 3.0 8-29
TeamPoS 2000 MAINTENANCE MANUAL
