5.5.1 TeamUSB Board. USB Connectors - 7 Ports
The TeamUSB board can only be used with the new riser card (Pin #KD20033-B41X).
When using the TeamUSB with the Pentium III motherboard, one of the USB ports on
the motherboard is used to connect the I/O board and a label covers one of the USB
connectors.
Pin # DC-Out Mode
1 5 VDC USB Power
Std. USB
Signals
2 Data -
3 Data +
4 Ground
5 24 VDC Return, USB ports 1, 2, 3 and 4
12 VDC Return, USB port 5, 6 & 7
12 or 24 VDC
Power
6 24 VDC Power, USB ports 1, 2, 3 and 4
12 VDC Power, USB port 5, 6 & 7
7 24 VDC Power, USB ports 1, 2, 3 and 4
12 VDC Power, USB port 5, 6 & 7
8 24 VDC Return, USB ports 1, 2, 3 and 4
12 VDC Returnr, USB port 5, 6 & 7
5-24 Rev 3.0 90000291
TeamPoS 2000 MAINTENANCE MANUAL
Note: There are two riser cards: Pin #CA21259-B21X supports Retail I/O and
TeamCOMBO options only, PIN #KD20033-B41X supports all I/O Boards.
