5.10.3 A12/D12 Cable Summary
LCD Power cables for single LCDs:
CA05951-3111 CBL D12 PWR Stacked/0.65M (*)
CA05951-3112 CBL D12 PWR Dispersed/2.0 M
CA05951-3113 CBL D12 PWR Dispersed/5.0M
Audio Cables, 1 required for each speaker option:
CA05951-3131 CBL D12 Audio/Stacked/0.65M
CA05951-3132 CBL D12 Audio/Dispersed/2.0M
CA05951-3133 CBL D12 Audio/Dispersed/5.0M
Digital cables, 1 required for each digital LCD:
CA05951-3101 CBL D12 Stacked/0.65M
CA05951-3102 CBL D12 Dispersed/2.0M
CA05951-3103 CBL D12 Dispersed/5.0M
Analog Data Cables, 1 required for each Analog LCD:
CA05951-5021 CBL A12 Analog Data/Stkd/0.65M
CA05951-5022 CBL A12 Analog Data/Disp/2.0M
CA05951-5023 -CBL A12 Analog Data/Disp/5.0M
Touch cables, 1 required for each touch screen:
CA05951-3121 CBL D12 TCH Screen/Stked/0.65M
CA05952-3122 CBL D12 TCH Screen/Disp/2.0M
CA05951-3123 CBL D12 TCH Screen/Disp/5.0M
Dual LCD Power (Y) cables, 1 cable powers both the digital and
the analog LCD (**):
CA05951-6061 CBL D12/A12 PWR Dual LCD/2.0M
CA05951-6062 CBL D12/A12 PWR Dual LCD/5.0M
(*) For stacked dual LCDs, 2 required (**) For stacked dual LCDs, two 0.65 meter cables can be used.
Notes:
• The application software will determine where the touch panels connect to the TeamPoS 2000. The touch cables can be connected to one
of the PC board's COM ports or any male 5VDC connector on the Retail I/O Board (Ports 1, 2 or 5) or TeamCOMBO Board (Port 1 or 2).
• TeamKey Cable Requirements:
There are two TeamKey options:
MSR only
Keypad & MSR
For either option , in addition to the listed cables, one of the following cables is required:
90000363 CBL D12 LCD KYB/0.8M
90000364 CBL D12 LCD KYB/2.0M
90000365 CBL D12 LCD KYB/5.0M
5-60 Rev 3.0 90000291
TeamPoS 2000 MAINTENANCE MANUAL
Note: In most cases, cable length will be the same
